EMC Design for Switching Power Converters
Provides 6 hours towards CPD
Included with Subscription.
Details
This module is designed to help electronic designers of products involved with DC/DC, DC/AC, AC/DC and AC/AC from milliwatts to Megawatts in all applications, including cellphones, computers, hybrid & electric vehicles, renewable (solar, wind, tidal, etc.), etc.
Module is 376 slides over 188 pages
Contents
- Very brief introduction to EMI and EMC
- Applications of switch-mode power conversion
- EMC design of switchers and choppers
- EMC design of high-frequency isolating transformers
- EMC design of output rectifiers
- Suppressing RF emissions from converter inputs and outputs
- Insulated Neutral, “floating”, mains power systems
- Miscellaneous switcher design issues
- Mains rectifiers – Power Factor Correction (PFC)
- Suppressing emissions of mains harmonic currents
- Suppressing emissions of voltage fluctuations and flicker
- Some useful references and further reading
