Dr. Min Zhang's latest blog: Validation of ESD Current Waveform Using an RF Current Probe
06 Dec 2023
Dr. Min Zhang's latest blog, "Validating ESD Current Waveform Using an RF Probe," offers a swift solution for a quick ESD waveform check.
EMC troubleshooting is a common task, and deviations in Electrostatic Discharge (ESD) simulator waveforms can pose challenges. This article, inspired by D. Smith's original method, swiftly checks if simulators align with expectations.
The setup comprises ground planes, an RF current monitor probe, and an oscilloscope. By focusing on waveform reliability rather than strict adherence to standards, this approach ensures efficient troubleshooting.
Discover more in Dr. Zhang's blog Validation of ESD Current Waveform Using an RF Current Probe, for a quick yet effective way to assess ESD simulator waveforms in EMC consulting.
